When muscles contract, they shorten and generate tension because tiny protein filaments inside them slide past each other, pulling your bones and producing movement.

What happens overall when muscles contract?

  • The muscle shortens and thickens, so the ends of the muscle (where it attaches to bone) are pulled closer together.
  • Tension (force) increases inside the muscle, which is what lets you lift a weight, hold a posture, or move a joint.
  • After the contraction, the muscle relaxes, lengthens back toward its resting state, and tension falls.

A simple example: when you do a biceps curl, your biceps contract, shorten, and pull your forearm up toward your shoulder.

Inside the muscle fiber: the sliding filament idea

Deep inside each muscle cell are repeating units called sarcomeres, made mainly of two proteins: actin (thin filaments) and myosin (thick filaments).

  • During contraction, actin filaments slide over myosin filaments, so the sarcomere becomes shorter, even though the individual filaments do not actually shrink.
  • The I band and H zone (regions with only thin or only thick filaments) get narrower, and overall sarcomere length decreases.

This “sliding filament” mechanism is what turns microscopic movements into visible muscle shortening.

Step‑by‑step: from nerve signal to contraction

  1. A nerve impulse (action potential) travels down a motor neuron to the neuromuscular junction, the contact point with the muscle fiber.
  1. The nerve ending releases the neurotransmitter acetylcholine, which binds to receptors on the muscle cell membrane and triggers an electrical signal in the muscle fiber.
  1. This signal spreads along the membrane and down T‑tubules, reaching deep into the cell and causing the sarcoplasmic reticulum to release calcium ions.
  1. Calcium binds to troponin on the thin filament, shifting tropomyosin away and exposing binding sites on actin.
  1. Myosin heads bind to these sites, forming cross‑bridges, and use energy from ATP to pivot (the “power stroke”), pulling actin inward and shortening the sarcomere.
  1. New ATP lets myosin detach, re‑cock, and repeat the cycle as long as calcium and ATP are available, maintaining contraction.

When calcium is pumped back into the sarcoplasmic reticulum and no longer binds troponin, the binding sites on actin are covered again and the muscle relaxes.

Types of contraction (what you feel)

  • Concentric : Muscle shortens while producing force (e.g., lifting a dumbbell).
  • Eccentric : Muscle lengthens while controlling force (e.g., lowering the dumbbell slowly).
  • Isometric : Muscle produces tension without changing length (e.g., holding a weight still in place).

Even though they feel different, all of these rely on the same basic cross‑bridge and sliding‑filament events inside the fibers.
